Stainless Steel 310 Seamless Pipes

What is Stainless Steel 310 Seamless Pipe?

Stainless Steel 310 Seamless Pipe is an austenitic stainless steel pipe designed for applications that require excellent resistance to elevated temperatures, oxidation and thermal cycling. Manufactured without a longitudinal welded seam, SS 310 Seamless Pipes provide consistent structural integrity and are suitable for demanding industrial services involving heat and corrosive environments.

Kamal Steels supplies Stainless Steel 310 Seamless Pipes and ASTM A312 TP310 Seamless Pipes in various sizes, schedules, wall thicknesses, lengths and finishes. Grade 310 is widely selected for high-temperature process equipment, furnaces, heat-treatment systems, petrochemical facilities, power generation and other industrial applications where reliable performance at elevated temperatures is required.

Stainless Steel 310 Seamless Pipe Specifications

Table of Contents

SS 310 Seamless Pipe Specifications

Specification Details
Product Name Stainless Steel 310 Seamless Pipe
Grade SS 310 / Type 310
UNS S31000
EN Grade 1.4841
Material Type Austenitic Stainless Steel
Manufacturing Process Seamless
Product Standard ASTM A312
ASME Specification ASME SA312
Size Range 1/8" to 24" and above as required
Schedule 5S, 10S, 40S, 80S, 160 and other schedules
Wall Thickness As per applicable schedule or specified requirement
Length Random, Double Random or Fixed Length
End Type Plain End, Bevelled End or Threaded End as required
Surface Finish Pickled & Passivated, Annealed, Bright Annealed or Polished
Heat Treatment Solution Annealed and Rapidly Cooled as specified by the applicable standard
Testing Hydrostatic, PMI, Ultrasonic, Flattening, Flaring and other applicable tests
Inspection Third Party Inspection available as required
Certification EN 10204 3.1 / Material Test Certificate (MTC)
Packaging Bundles, Wooden Cases, Wooden Boxes, Plastic End Caps and Export Packing
Get SS 310 Pipe Quote

SS 310 Seamless Pipe Size Chart

SS 310 Seamless Pipes are available in a broad range of nominal pipe sizes and outside diameters for different industrial piping requirements. Size selection depends on the required flow capacity, operating conditions, wall thickness, pressure requirements and applicable piping specifications.

Nominal Pipe Size Outside Diameter Common Application
1/2 Inch 21.3 mm Instrumentation and utility lines
1 Inch 33.4 mm Process and utility piping
2 Inch 60.3 mm Process piping
3 Inch 88.9 mm Industrial piping systems
4 Inch 114.3 mm Process and plant piping
6 Inch 168.3 mm Industrial fluid transfer
8 Inch 219.1 mm Large process piping

Other SS 310 Seamless Pipe Sizes and custom dimensions can be supplied depending on the applicable standard, manufacturing feasibility and project requirements.

SS 310 Seamless Pipe Weight Chart

The weight of Stainless Steel 310 Seamless Pipe depends mainly on its outside diameter, wall thickness and pipe length. Heavier schedules have greater wall thickness and therefore result in higher weight per metre. Actual supplied weight may vary according to dimensional tolerances and manufacturing requirements.

Pipe Size Typical Schedule Approx. Weight
1 Inch SCH 40S Approx. 2.09 kg/m
2 Inch SCH 40S Approx. 5.44 kg/m
3 Inch SCH 40S Approx. 7.67 kg/m
4 Inch SCH 40S Approx. 10.79 kg/m
6 Inch SCH 40S Approx. 16.10 kg/m

For accurate SS 310 Seamless Pipe weight calculations, the exact outside diameter, wall thickness and length should be considered. Weight can also vary depending on the applicable dimensional standard.

SS 310 Seamless Pipe Schedule Chart

Stainless Steel 310 Seamless Pipes are available in different schedules to accommodate varying pressure, temperature and mechanical service requirements. The selected schedule determines the nominal wall thickness for a particular pipe size.

Schedule Typical Description Application Consideration
SCH 5S Light wall Suitable for specified low-pressure services
SCH 10S Light to medium wall Process and utility applications
SCH 40S Standard wall range General industrial piping
SCH 80S Heavy wall Higher pressure service requirements
SCH 160 Extra heavy wall Specified demanding pressure applications

ASTM A312 TP310 Seamless Pipe

ASTM A312 TP310 Seamless Pipe is manufactured from Type 310 austenitic stainless steel according to the applicable ASTM A312 requirements. This specification covers seamless, welded and heavily cold-worked austenitic stainless steel pipe intended for corrosive and high-temperature service.

SS 310 seamless pipe supplied to ASTM A312 requirements can be selected in different sizes, schedules and wall thicknesses depending on the application. The applicable edition of the specification, dimensions, testing requirements and supplementary requirements should be confirmed before procurement.

For ASME applications, the corresponding material designation may be referenced as ASME SA312, subject to the applicable Code and project requirements.

SS 310 Seamless Pipe Chemical Composition & Mechanical Properties

Stainless Steel 310 is an austenitic chromium-nickel stainless steel with a composition designed to provide strong oxidation resistance and useful performance in elevated-temperature environments.

Element Typical / Specification Range
Chromium 24.0–26.0%
Nickel 19.0–22.0%
Carbon 0.25% max.
Manganese 2.00% max.
Silicon 1.50% max.
Phosphorus 0.045% max.
Sulfur 0.030% max.
Iron Balance

SS 310 Seamless Pipes provide good tensile strength, yield strength and elongation in accordance with the applicable product specification. Mechanical properties can vary with product form, heat treatment, dimensions and the specific standard or specification being followed.

SS 310 vs SS 310S Seamless Pipe

SS 310 and SS 310S are closely related austenitic stainless steel grades used for high-temperature applications. The main difference is the carbon content, with 310S having a lower maximum carbon level than Grade 310. This difference can influence fabrication and service considerations depending on the application.

Feature SS 310 SS 310S
UNS S31000 S31008
Carbon Higher maximum carbon content Lower maximum carbon content
Temperature Service High-temperature applications High-temperature applications
Oxidation Resistance Excellent Excellent
Selection Based on applicable service requirements Often selected where lower carbon is preferred

SS 310 Seamless Pipe vs Welded Pipe

Both seamless and welded stainless steel pipes can be used in industrial applications, but their manufacturing processes are different. 310 SS Tubing is produced from a solid billet, while welded pipe is manufactured from a plate or strip that is formed and joined along a longitudinal seam.

Feature SS 310 Seamless Pipe SS 310 Welded Pipe
Manufacturing Produced from a pierced billet Produced from formed strip or plate with a welded seam
Longitudinal Seam No welded longitudinal seam Contains a welded longitudinal seam
Size Availability Available in various standard sizes Wide range of sizes and larger diameters can be available
Typical Selection Selected where seamless construction is specified Selected where welded construction is suitable

SS 310 Seamless Pipe Price

The price of Stainless Steel 310 Seamless Pipe depends on several factors, including pipe size, wall thickness, schedule, length, quantity, surface finish, testing, certification, packaging and prevailing stainless steel raw material costs.

For an accurate SS 310 Seamless Pipe price quotation, buyers should provide the required grade, pipe size, schedule or wall thickness, quantity, length, applicable standard, testing requirements and delivery destination. Kamal Steels can review these details and provide a quotation based on the specified requirements.

SS 310 Seamless Pipe Applications & Industries

Stainless Steel 310 Seamless Pipes are used across industrial sectors where high-temperature performance, oxidation resistance, corrosion resistance and mechanical strength are required. Common applications include process equipment, heat-treatment systems and high-temperature industrial piping.

Heat Treatment

Industry: Heat Treatment

Application: Furnace components, heating systems, thermal processing equipment and high-temperature piping.

Chemical Processing

Industry: Chemical Processing

Application: High-temperature process lines, chemical handling systems and industrial process equipment.

Petrochemical

Industry: Petrochemical

Application: Process piping, plant equipment, high-temperature service and fluid transfer systems.

Power Generation

Industry: Power Generation

Application: High-temperature piping, thermal systems and process equipment.

Industrial Furnaces

Industry: Industrial Furnace Systems

Application: Furnace piping, combustion systems, thermal equipment and high-temperature service.

Engineering & Fabrication

Industry: Engineering & Fabrication

Application: Industrial equipment, fabricated systems, high-temperature components and process piping.

The appropriate SS 310 Seamless Pipe size, wall thickness, schedule, temperature range, testing and applicable piping code should be evaluated according to the actual service conditions before selection.

Kamal Steels supplies Stainless Steel 310 Seamless Pipes for domestic and international requirements with support for applicable specifications, inspection requirements, material documentation and export packaging.

Frequently Asked Questions

Stainless Steel 310 Seamless Pipe is a high chromium and high nickel austenitic stainless steel pipe manufactured without welded joints. It is specifically designed for high-temperature applications requiring exceptional oxidation resistance, corrosion resistance and mechanical strength.

ASTM A312 TP310 Seamless Pipe is manufactured according to ASTM A312 specifications and is widely used in high-temperature service applications such as furnaces, heat treatment equipment, petrochemical plants and power generation facilities.

Stainless Steel 310 Seamless Pipes are commonly used in industrial furnaces, heat exchangers, boilers, petrochemical plants, refineries, power plants, thermal processing equipment and chemical processing industries.

SS 310 Pipes can withstand continuous service temperatures up to approximately 1100°C and intermittent temperatures up to 1035°C while maintaining excellent oxidation resistance and structural stability.

SS 310 contains significantly higher chromium and nickel content than SS 304, providing superior heat resistance, oxidation resistance and elevated-temperature performance. SS 304 is generally used for standard corrosion-resistant applications.

Stainless Steel 310 Seamless Pipes are available in sizes ranging from 1/2" NB to 24" NB with schedules including SCH 5S, SCH 10S, SCH 40S, SCH 80S, SCH 160 and XXS.

Stainless Steel 310 is internationally recognized as UNS S31000, WNR 1.4845 and EN X15CrNi25-20. These equivalent grades are widely accepted in global engineering and industrial projects.

The price of Stainless Steel 310 Seamless Pipes depends on size, schedule, wall thickness, quantity, testing requirements and market conditions. Contact Kamal Steels for the latest SS 310 Pipe Price and stock availability.

Yes, all Stainless Steel 310 Seamless Pipes can be supplied with Mill Test Certificates (MTC) as per EN 10204 3.1 and Third-Party Inspection (TPI) reports from approved inspection agencies upon request.

Kamal Steels is a trusted Stainless Steel 310 Seamless Pipe Manufacturer, Supplier and Stockist in India. We offer ready stock, competitive pricing, quality certifications, fast delivery, export support and complete documentation for industrial projects worldwide.
