Aluminium 1100 Pipes Exporter in India
What Are Aluminium 1100 Pipes?
Aluminium 1100 Pipes are manufactured from commercially pure Aluminium 1100, an aluminium grade known for its excellent corrosion resistance, high ductility, formability and thermal and electrical conductivity. The alloy is identified by UNS A91100 and is widely used where high formability and corrosion resistance are more important than high mechanical strength.
Aluminium 1100 contains a minimum of 99.0% aluminium, with small controlled amounts of other elements. Its excellent workability makes it suitable for forming, bending, drawing and fabrication. Aluminium 1100 Pipes can be supplied in suitable tempers and dimensions according to the applicable product specification and customer requirements.
These pipes are used in applications such as heat exchangers, HVAC systems, food processing equipment, chemical handling, general engineering, electrical applications and architectural components. Their lightweight construction and resistance to atmospheric corrosion make them suitable for a wide range of industrial and commercial applications.
Kamal Steels is a reliable Aluminium 1100 Pipes Exporter and Supplier in India, offering pipes in different sizes, wall thicknesses, lengths and tempers. We supply Aluminium 1100 Pipes for domestic and international requirements according to applicable specifications and customer requirements.
Table of Contents
- Aluminium 1100 Pipe Specifications
- Aluminium 1100 Pipe Size Chart
- Aluminium 1100 Pipe Weight Chart
- Aluminium 1100 Pipe Schedule Chart
- ASTM B241 Aluminium 1100 Pipe
- Aluminium 1100 Pipe Features
- Aluminium 1100 Pipe Chemical Composition
- Aluminium 1100 Pipe Mechanical Properties
- Aluminium 1100 Pipe Equivalent Grades
- Aluminium 1100 Pipe vs Other Aluminium Grades
- Aluminium 1100 Pipe Applications
- Industries Using Aluminium 1100 Pipes
- Frequently Asked Questions
Aluminium 1100 Pipe Specifications
Kamal Steels supplies and exports Aluminium 1100 Pipes manufactured in accordance with internationally recognized ASTM, ASME, and EN standards. Produced from premium-quality Aluminium Alloy 1100, these pipes offer excellent corrosion resistance, superior thermal and electrical conductivity, outstanding formability, and reliable weldability. Our Aluminium 1100 Pipes are available in seamless and welded forms with multiple diameters, wall thicknesses, tempers, and custom lengths to meet the requirements of chemical processing, food processing, heat exchangers, architectural, and industrial engineering applications.
| Product | Aluminium 1100 Pipes |
|---|---|
| Material Grade | Aluminium Alloy 1100 (UNS A91100) |
| Specifications | ASTM B210, ASTM B241, ASTM B345, ASME SB210, ASME SB241 |
| Pipe Type | Seamless & Welded |
| Outside Diameter | 6 mm to 250 mm |
| Wall Thickness | 0.5 mm to 25 mm |
| Temper | O, H12, H14, H16, H18 |
| Length | 3 Meter, 6 Meter & Custom Cut Lengths |
| Surface Finish | Mill Finish, Polished, Anodized |
| Certification | EN 10204 3.1 Mill Test Certificate (MTC) |
Aluminium 1100 Pipe Size Chart
Aluminium 1100 Pipes are available in different outside diameters and wall thicknesses to suit various fabrication, fluid transfer and engineering requirements. Standard and customized dimensions can be supplied according to the applicable specification and project requirements.
| Nominal Pipe Size | DN | Outside Diameter (OD) mm | Outside Diameter (OD) inch | Wall Thickness |
|---|---|---|---|---|
| 1/2" | 15 | 21.34 | 0.840 | As per requirement |
| 3/4" | 20 | 26.67 | 1.050 | As per requirement |
| 1" | 25 | 33.40 | 1.315 | As per requirement |
| 1-1/4" | 32 | 42.16 | 1.660 | As per requirement |
| 1-1/2" | 40 | 48.26 | 1.900 | As per requirement |
| 2" | 50 | 60.33 | 2.375 | As per requirement |
| 2-1/2" | 65 | 73.03 | 2.875 | As per requirement |
| 3" | 80 | 88.90 | 3.500 | As per requirement |
| 4" | 100 | 114.30 | 4.500 | As per requirement |
| 6" | 150 | 168.28 | 6.625 | As per requirement |
| 8" | 200 | 219.08 | 8.625 | As per requirement |
Kamal Steels can supply Aluminium 1100 Pipes in customized outside diameters, wall thicknesses and lengths according to customer and project requirements.
Aluminium 1100 Pipe Weight Chart
The weight of an Aluminium 1100 Pipe depends on its outside diameter, wall thickness and length. The following values are approximate theoretical weights based on nominal dimensions and the typical density of Aluminium 1100. Actual supplied weight may vary according to dimensional tolerances and manufacturing conditions.
| Nominal Pipe Size | Outside Diameter (mm) | Wall Thickness (mm) | Inside Diameter (mm) | Approx. Weight (kg/m) |
|---|---|---|---|---|
| 1/2" | 21.34 | 2.77 | 15.80 | 0.44 |
| 3/4" | 26.67 | 2.87 | 20.93 | 0.59 |
| 1" | 33.40 | 3.38 | 26.64 | 0.89 |
| 1-1/4" | 42.16 | 3.56 | 35.04 | 1.20 |
| 1-1/2" | 48.26 | 3.68 | 40.90 | 1.43 |
| 2" | 60.33 | 3.91 | 52.51 | 1.93 |
| 2-1/2" | 73.03 | 5.16 | 62.71 | 3.05 |
| 3" | 88.90 | 5.49 | 77.92 | 3.98 |
| 4" | 114.30 | 6.02 | 102.26 | 5.65 |
| 6" | 168.28 | 7.11 | 154.06 | 9.96 |
| 8" | 219.08 | 7.04 | 205.00 | 12.98 |
Note: Weight values are approximate and should be used for reference only. Final weight depends on the actual outside diameter, wall thickness, length and dimensional tolerances of the supplied pipe.
Aluminium 1100 Pipe Schedule Chart
Aluminium 1100 Pipes can be supplied with different wall thicknesses according to pipe size, application and dimensional requirements. Schedule references can be used for general pipe sizing, while the actual required wall thickness should be confirmed against the applicable dimensional standard and purchase specification.
| Nominal Pipe Size | Outside Diameter (mm) | Schedule | Wall Thickness (mm) |
|---|---|---|---|
| 1/2" | 21.34 | 40 | 2.77 |
| 3/4" | 26.67 | 40 | 2.87 |
| 1" | 33.40 | 40 | 3.38 |
| 1-1/4" | 42.16 | 40 | 3.56 |
| 1-1/2" | 48.26 | 40 | 3.68 |
| 2" | 60.33 | 40 | 3.91 |
| 2-1/2" | 73.03 | 40 | 5.16 |
| 3" | 88.90 | 40 | 5.49 |
| 4" | 114.30 | 40 | 6.02 |
| 6" | 168.28 | 40 | 7.11 |
| 8" | 219.08 | 40 | 7.04 |
Other wall thicknesses and customized dimensions can be supplied according to customer requirements and applicable product specifications.
ASTM B241 Aluminium 1100 Pipe
ASTM B241 Aluminium 1100 Pipes are supplied according to the applicable requirements for aluminium-alloy seamless pipe and seamless extruded tube. Aluminium 1100, designated as UNS A91100, is a commercially pure aluminium alloy that provides excellent corrosion resistance, ductility and formability.
Aluminium 1100 is particularly suitable for applications where high strength is not the primary requirement. Its excellent workability makes it useful for forming, bending, fabrication and applications requiring good thermal and electrical conductivity.
| Specification | Details |
|---|---|
| ASTM Standard | ASTM B241 / B241M |
| Aluminium Grade | 1100 |
| UNS | A91100 |
| Alloy Series | 1000 Series |
| Alloy Type | Commercially Pure Aluminium |
| Product Form | Seamless Pipe / Seamless Extruded Tube |
| Common Tempers | O, H12, H14, H16 and H18 |
Aluminium 1100 Pipe Features
Aluminium 1100 Pipes offer a combination of lightweight construction, excellent corrosion resistance and high ductility. The alloy can be readily formed and fabricated, making it suitable for applications where ease of processing is important.
- Excellent corrosion resistance
- High ductility
- Excellent formability
- Good weldability
- Good thermal conductivity
- Good electrical conductivity
- Lightweight construction
- Excellent workability
- Suitable for bending and fabrication
Aluminium 1100 Pipe Chemical Composition
Aluminium 1100 is a commercially pure aluminium alloy containing a minimum of 99.0% aluminium. The remaining composition consists of small controlled quantities of elements such as copper, iron, silicon, manganese, zinc and other residual elements.
| Element | Composition (%) |
|---|---|
| Silicon + Iron | 1.00 max. |
| Copper | 0.05 - 0.20 |
| Manganese | 0.05 max. |
| Zinc | 0.10 max. |
| Other Elements | 0.05 max. each / 0.15 max. total |
| Aluminium | 99.00 min. |
Aluminium 1100 Pipe Mechanical Properties
The mechanical properties of Aluminium 1100 Pipes depend on the selected temper and product dimensions. Cold-worked tempers such as H14 and H18 provide higher strength than the annealed O temper, while maintaining the alloy's characteristic formability and corrosion resistance.
| Property | Aluminium 1100-O | Aluminium 1100-H14 | Aluminium 1100-H18 |
|---|---|---|---|
| Tensile Strength | Approx. 90 MPa | Approx. 125 MPa | Approx. 165 MPa |
| Yield Strength | Approx. 35 MPa | Approx. 115 MPa | Approx. 150 MPa |
| Elastic Modulus | Approx. 69 GPa | ||
| Elongation | High | Moderate | Lower than O and H14 |
Note: Mechanical property values can vary with temper, product form and dimensions. The material test certificate should be used for confirmation of the properties of the supplied Aluminium 1100 Pipes.
Aluminium 1100 Pipe Mechanical Properties
The mechanical properties of Aluminium 1100 Pipes depend on the selected temper and product dimensions. Cold-worked tempers such as H14 and H18 provide higher strength than the annealed O temper, while maintaining the alloy's characteristic formability and corrosion resistance.
| Property | Aluminium 1100-O | Aluminium 1100-H14 | Aluminium 1100-H18 |
|---|---|---|---|
| Tensile Strength | Approx. 90 MPa | Approx. 125 MPa | Approx. 165 MPa |
| Yield Strength | Approx. 35 MPa | Approx. 115 MPa | Approx. 150 MPa |
| Elastic Modulus | Approx. 69 GPa | ||
| Elongation | High | Moderate | Lower than O and H14 |
Note: Mechanical property values can vary with temper, product form and dimensions. The material test certificate should be used for confirmation of the properties of the supplied Aluminium 1100 Pipes.
Aluminium 1100 Pipe Equivalent Grades
Aluminium 1100 is identified through internationally recognized alloy and material designation systems. These designations are useful when specifying the alloy during procurement and material selection.
| Designation | Aluminium 1100 |
|---|---|
| Aluminium Alloy | 1100 |
| UNS | A91100 |
| Alloy Series | 1000 Series |
| Common Tempers | O, H12, H14, H16, H18 |
Aluminium 1100 Pipe vs Other Aluminium Grades
Aluminium grades differ in strength, corrosion resistance, formability, machinability and fabrication characteristics. Aluminium 1100 is generally selected when excellent formability, corrosion resistance and conductivity are more important than high mechanical strength.
| Grade | Main Characteristics | Typical Applications |
|---|---|---|
| Aluminium 1100 | Excellent formability, corrosion resistance and conductivity | Heat exchangers, HVAC, food processing and general fabrication |
| Aluminium 5052 | Good corrosion resistance, formability and higher strength | Marine, transportation and fabricated applications |
| Aluminium 6061 | Higher strength, good machinability and weldability | Structural and general engineering applications |
| Aluminium 6063 | Excellent extrusion characteristics and surface finish | Architectural, construction and tubular applications |
| Aluminium 7075 | High strength-to-weight ratio | Aerospace and high-performance applications |
Aluminium 1100 Pipe Applications
Aluminium 1100 Pipes are used in applications where lightweight construction, corrosion resistance, high formability and good thermal or electrical conductivity are required. The alloy is particularly suitable for applications that involve bending, forming or fabrication.
Heat Exchangers
Used in selected heat transfer components because of aluminium's good thermal conductivity.
HVAC Systems
Used in selected heating, ventilation and air-conditioning components and fabricated systems.
Chemical Equipment
Used in suitable chemical handling and processing applications where corrosion resistance is required.
Food Processing
Used in selected food processing and handling equipment because of its corrosion resistance and formability.
Electrical Applications
Used in applications where good electrical conductivity and lightweight construction are required.
Architectural Applications
Used in lightweight fabricated sections and architectural components.
Industries Using Aluminium 1100 Pipes
Kamal Steels supplies Aluminium 1100 Pipes to industries requiring lightweight, corrosion-resistant and highly formable aluminium piping solutions. Pipes can be supplied in suitable sizes, wall thicknesses, lengths and tempers according to project requirements.
HVAC Industry
Used in selected heating, ventilation and air-conditioning equipment and systems.
Engineering Industry
Used for fabricated components and general engineering applications.
Chemical Industry
Used in suitable corrosion-resistant equipment and fluid handling applications.
Food Processing Industry
Used in selected processing and handling equipment requiring lightweight aluminium components.
Electrical Industry
Used in applications requiring lightweight components with good electrical conductivity.
Construction Industry
Used in suitable lightweight architectural and fabricated construction components.
Frequently Asked Questions
Aluminium 1100 Pipes are manufactured from Aluminium Alloy 1100 (UNS A91100), a commercially pure aluminium alloy containing a minimum of 99% aluminium, known for its excellent corrosion resistance, superior conductivity, and outstanding formability.
Aluminium 1100 Pipes are supplied according to ASTM B210, ASTM B241, ASTM B345, ASME SB210, and ASME SB241 standards, ensuring excellent quality and dimensional accuracy.
Aluminium 1100 Pipes offer outstanding corrosion resistance, excellent thermal and electrical conductivity, superior weldability, excellent formability, lightweight construction, and easy fabrication.
They are widely used in chemical processing plants, food processing equipment, heat exchangers, storage tanks, HVAC systems, electrical applications, pharmaceutical industries, and architectural projects.
Yes. Aluminium 1100 Pipes are available in both seamless and welded forms in various diameters, wall thicknesses, tempers, and custom lengths to meet diverse industrial requirements.
Every Aluminium 1100 Pipe undergoes Chemical Composition Analysis, Mechanical Testing, Tensile Testing, Hardness Testing, Dimensional Inspection, Ultrasonic Testing (UT), Positive Material Identification (PMI), and Visual Examination before dispatch.
Yes. Aluminium 1100 offers excellent corrosion resistance, non-toxic properties, and outstanding formability, making it suitable for food processing and food handling equipment.
Yes. Aluminium 1100 provides excellent electrical conductivity, making it widely used in electrical conductors, busbars, and power distribution equipment.
Yes. Every shipment includes EN 10204 3.1 Mill Test Certificates, complete material traceability, inspection reports, and third-party inspection certificates upon customer request.
Kamal Steels is a trusted exporter and supplier of Aluminium 1100 Pipes, offering certified materials, ready stock, competitive pricing, strict quality control, export-quality packaging, complete documentation, and timely worldwide delivery for industrial and engineering applications.
