Nickel 201 Tubes Supplier in India
What Are Nickel 201 Tubes?
Nickel 201 Tubes are commercially pure nickel tubes with a low carbon content, offering excellent corrosion resistance, good ductility, thermal conductivity and reliable performance in reducing and caustic environments. Nickel 201, designated as UNS N02201, is a low-carbon version of Nickel 200 and is particularly suitable for applications involving elevated temperatures.
Nickel 201 Tubes are valued for their excellent resistance to caustic alkalis, good resistance to reducing environments, high ductility, good thermal and electrical conductivity and lower carbon content. The low carbon composition helps reduce the risk of carbon embrittlement and makes Nickel 201 more suitable than Nickel 200 for certain higher-temperature applications.
These tubes are used in chemical processing equipment, caustic handling systems, heat exchangers, food processing equipment, electrical components, aerospace systems and specialized industrial equipment. The required tube size, wall thickness, length, finish and material condition are selected according to the specific application and operating conditions.
Kamal Steels is a reliable Nickel 201 Tubes Supplier and Exporter in India, supplying tubes in different sizes, wall thicknesses, lengths and finishes according to customer and project requirements. We also cater to international requirements with suitable export packaging and documentation.
Table of Contents
- Nickel 201 Tube Specifications
- Nickel 201 Tube Size Chart
- Nickel 201 Tube Weight Chart
- Nickel 201 Tube Standards
- Nickel 201 Tube Features
- Nickel 201 Tube Chemical Composition
- Nickel 201 Tube Mechanical Properties
- Nickel 201 Tube Equivalent Grades
- Nickel 201 Tube vs Nickel 200 Tube
- Nickel 201 Tube Applications
- Industries Using Nickel 201 Tubes
- Frequently Asked Questions
Nickel 201 Tube Specifications
Nickel 201 Tubes are supplied according to applicable nickel-alloy standards and customer requirements. The low carbon content of this commercially pure nickel grade provides improved suitability for certain elevated-temperature applications.
| Specification | Nickel 201 Tubes |
|---|---|
| Material | Commercially Pure Nickel |
| Grade | Nickel 201 |
| UNS | N02201 |
| ASTM Tube Standard | ASTM B161 |
| ASME Standard | ASME SB161 |
| Tube Type | Seamless / As specified |
| Outside Diameter | As per requirement |
| Wall Thickness | As per requirement |
| Length | Random, Fixed or Customized |
| Finish | Annealed / Pickled / As required |
Nickel 201 Tube Size Chart
Nickel 201 Tubes are available in different outside diameters and wall thicknesses for chemical processing, heat-transfer and specialized industrial applications. Customized dimensions can also be supplied according to customer drawings and project requirements.
| Tube Size | Outside Diameter (mm) | Wall Thickness | Length |
|---|---|---|---|
| 1/4" | 6.35 | As required | As required |
| 1/2" | 12.70 | As required | As required |
| 3/4" | 19.05 | As required | As required |
| 1" | 25.40 | As required | As required |
| 1-1/2" | 38.10 | As required | As required |
| 2" | 50.80 | As required | As required |
| 3" | 76.20 | As required | As required |
| 4" | 101.60 | As required | As required |
| 6" | 152.40 | As required | As required |
Nickel 201 Tube Weight Chart
The theoretical weight of Nickel 201 Tubes depends on outside diameter, wall thickness and length. The following values are approximate reference values based on the typical density of Nickel 201.
| Outside Diameter (mm) | Wall Thickness (mm) | Inside Diameter (mm) | Approx. Weight (kg/m) |
|---|---|---|---|
| 12.70 | 1.00 | 10.70 | 0.36 |
| 19.05 | 1.50 | 16.05 | 0.84 |
| 25.40 | 2.00 | 21.40 | 1.55 |
| 31.75 | 2.50 | 26.75 | 2.44 |
| 38.10 | 3.00 | 32.10 | 3.44 |
| 50.80 | 3.00 | 44.80 | 4.76 |
| 63.50 | 3.00 | 57.50 | 6.08 |
| 76.20 | 4.00 | 68.20 | 9.71 |
| 101.60 | 5.00 | 91.60 | 15.80 |
Note: The values shown are approximate theoretical weights. Actual tube weight may vary according to dimensions, tolerances, density and manufacturing conditions.
Nickel 201 Tube Standards
Nickel 201 Tubes can be supplied according to applicable ASTM, ASME and other industry specifications depending on product form, dimensions and application requirements.
| Standard / Designation | Details |
|---|---|
| UNS | N02201 |
| ASTM | ASTM B161 |
| ASME | ASME SB161 |
| Grade | Nickel 201 |
| Material Type | Low-Carbon Commercially Pure Nickel |
Nickel 201 Tube Features
Nickel 201 Tubes provide excellent corrosion resistance, good ductility and reliable performance in caustic and reducing environments. Its low carbon content makes the alloy particularly useful for certain elevated-temperature services.
- Low carbon content
- Excellent resistance to caustic alkalis
- Good resistance to reducing environments
- Excellent ductility and toughness
- Good thermal conductivity
- Good electrical conductivity
- Excellent corrosion resistance in suitable environments
- Good resistance to distilled and natural waters
- Better suitability for certain elevated-temperature applications than Nickel 200
- Suitable for chemical and industrial applications
Nickel 201 Tube Chemical Composition
Nickel 201 is a commercially pure nickel alloy with a high nickel content and a significantly lower carbon limit than Nickel 200. This controlled composition improves its suitability for certain higher-temperature applications.
| Element | Composition (%) |
|---|---|
| Nickel | 99.0 min. |
| Copper | 0.25 max. |
| Manganese | 0.35 max. |
| Iron | 0.40 max. |
| Silicon | 0.35 max. |
| Sulfur | 0.01 max. |
| Carbon | 0.02 max. |
Nickel 201 Tube Mechanical Properties
Nickel 201 offers good mechanical strength along with excellent ductility and toughness. Actual properties depend on product condition, dimensions, heat treatment and applicable specification.
| Property | Typical Value |
|---|---|
| Tensile Strength | Approx. 403 MPa |
| Yield Strength | Approx. 59 MPa |
| Elongation | Approx. 50% |
| Density | Approx. 8.89 g/cm³ |
| Melting Range | Approx. 1435 - 1446°C |
Note: Mechanical properties vary according to product form, dimensions, temper and applicable specification. Certified material test reports should be used for final verification.
Nickel 201 Tube Equivalent Grades
| Designation | Nickel 201 |
|---|---|
| UNS | N02201 |
| EN | 2.4068 |
| Trade Name | Nickel 201 |
| Material Type | Low-Carbon Commercially Pure Nickel |
Nickel 201 Tube vs Nickel 200 Tube
Nickel 200 and Nickel 201 are commercially pure nickel grades with similar corrosion resistance and physical properties. The main difference is carbon content. Nickel 201 has a much lower carbon content, making it more suitable for certain elevated-temperature applications.
| Property | Nickel 200 | Nickel 201 |
|---|---|---|
| UNS | N02200 | N02201 |
| Carbon Content | 0.15% max. | 0.02% max. |
| Corrosion Resistance | Excellent in suitable environments | Excellent in suitable environments |
| High-Temperature Suitability | More limited | Better suited to certain elevated-temperature applications |
| Typical Applications | Caustic handling and chemical processing | High-temperature chemical and industrial applications |
Nickel 201 Tube Applications
Nickel 201 Tubes are used in applications requiring commercially pure, low-carbon nickel with excellent corrosion resistance and reliable performance in reducing and caustic environments.
Chemical Processing
Used in chemical processing equipment exposed to caustic alkalis and selected reducing chemicals.
Caustic Handling
Used in equipment and systems handling sodium hydroxide and other alkaline solutions.
Heat Exchangers
Used in selected heat-transfer equipment where corrosion resistance and nickel's thermal properties are required.
Electrical Equipment
Used in specialized electrical and electronic applications requiring good conductivity and corrosion resistance.
Industrial Equipment
Used in specialized equipment requiring commercially pure nickel with a low carbon content.
High-Temperature Components
Used in selected elevated-temperature applications where Nickel 201's low carbon content provides an advantage.
Industries Using Nickel 201 Tubes
Kamal Steels supplies Nickel 201 Tubes to industries requiring low-carbon commercially pure nickel tubing for corrosive, chemical and elevated-temperature environments.
Chemical Industry
Used in chemical processing systems requiring corrosion-resistant nickel materials.
Petrochemical Industry
Used in selected process equipment and tubular systems operating in corrosive environments.
Electrical Industry
Used in specialized electrical and electronic components requiring good conductivity and corrosion resistance.
Power Generation Industry
Used in selected equipment requiring commercially pure nickel and reliable performance.
Engineering Industry
Used for specialized components and equipment requiring low-carbon nickel alloys.
Industrial Processing
Used in industrial systems requiring corrosion resistance and suitability for selected elevated-temperature services.
Frequently Asked Questions
Nickel 201 Tubes are commercially pure low-carbon nickel alloy tubes manufactured from Nickel 201 (UNS N02201 / WNR 2.4068). They are designed for applications requiring excellent corrosion resistance and improved performance at elevated temperatures.
Our Nickel 201 Tubes are manufactured according to ASTM B161, ASTM B163, ASTM B725, ASTM B730, ASME SB161, and ASME SB163 standards.
Nickel 201 Tubes provide excellent corrosion resistance, superior resistance to graphitization at elevated temperatures, outstanding thermal and electrical conductivity, excellent weldability, and long service life.
They are widely used in chemical processing plants, pharmaceuticals, food processing equipment, heat exchangers, electronics, marine engineering, power generation, and high-temperature industrial applications.
Nickel 201 has a lower carbon content than Nickel 200, providing improved resistance to graphitization and better performance during prolonged exposure to elevated temperatures.
Each tube undergoes PMI Testing, Chemical Analysis, Mechanical Testing, Hydrostatic Testing, Ultrasonic Testing (UT), Eddy Current Testing (ECT), Flattening, Flaring, Dimensional Inspection, and Visual Inspection.
Yes. Nickel 201 is specifically designed for elevated-temperature applications where resistance to graphitization and long-term structural stability are essential.
Yes. Every shipment includes EN 10204 3.1/3.2 Mill Test Certificates, inspection reports, complete material traceability, and third-party inspection certificates upon request.
Yes. Kamal Steels exports Nickel 201 Tubes worldwide with export-standard packaging, complete documentation, and timely international delivery.
Kamal Steels offers ASTM-compliant Nickel 201 Tubes with ready stock, certified quality, competitive pricing, stringent quality control, export-standard packaging, complete documentation, and dependable worldwide delivery for critical industrial applications.
