Nickel 200 Tubes Supplier in India
What Are Nickel 200 Tubes?
Nickel 200 Tubes are commercially pure nickel tubes containing a high percentage of nickel, offering excellent corrosion resistance, good mechanical properties and reliable performance in reducing environments. Nickel 200, designated as UNS N02200, is widely used in applications requiring high-purity nickel with good resistance to caustic alkalis and various corrosive media.
Nickel 200 Tubes are known for their excellent resistance to caustic soda and other alkaline solutions, good electrical and thermal conductivity, good ductility, high toughness and resistance to reducing chemicals. These properties make the alloy suitable for applications where corrosion resistance and material purity are important.
These tubes are used in chemical processing equipment, caustic handling systems, food processing equipment, heat exchangers, electronic components, aerospace systems and industrial processing equipment. The appropriate tube dimensions, wall thickness, length, finish and material condition are selected according to the specific application and operating requirements.
Kamal Steels is a reliable Nickel 200 Tubes Supplier and Exporter in India, supplying tubes in different sizes, wall thicknesses, lengths and finishes according to customer and project requirements. We also cater to international requirements with suitable export packaging and documentation.
Table of Contents
- Nickel 200 Tube Specifications
- Nickel 200 Tube Size Chart
- Nickel 200 Tube Weight Chart
- Nickel 200 Tube Standards
- Nickel 200 Tube Features
- Nickel 200 Tube Chemical Composition
- Nickel 200 Tube Mechanical Properties
- Nickel 200 Tube Equivalent Grades
- Nickel 200 Tube vs Nickel 201 Tube
- Nickel 200 Tube Applications
- Industries Using Nickel 200 Tubes
- Frequently Asked Questions
Nickel 200 Tube Specifications
Nickel 200 Tubes are manufactured and supplied according to applicable nickel-alloy standards and customer requirements. The material is valued for its high nickel content, corrosion resistance and good physical and mechanical properties.
| Specification | Nickel 200 Tubes |
|---|---|
| Material | Commercially Pure Nickel |
| Grade | Nickel 200 |
| UNS | N02200 |
| ASTM Tube Standard | ASTM B161 |
| ASME Standard | ASME SB161 |
| Tube Type | Seamless / As specified |
| Outside Diameter | As per requirement |
| Wall Thickness | As per requirement |
| Length | Random, Fixed or Customized |
| Finish | Annealed / Pickled / As required |
Nickel 200 Tube Size Chart
Nickel 200 Tubes are available in different outside diameters and wall thicknesses for chemical processing, heat-transfer and specialized industrial applications. Customized tube dimensions can also be supplied according to customer drawings and project requirements.
| Tube Size | Outside Diameter (mm) | Wall Thickness | Length |
|---|---|---|---|
| 1/4" | 6.35 | As required | As required |
| 1/2" | 12.70 | As required | As required |
| 3/4" | 19.05 | As required | As required |
| 1" | 25.40 | As required | As required |
| 1-1/2" | 38.10 | As required | As required |
| 2" | 50.80 | As required | As required |
| 3" | 76.20 | As required | As required |
| 4" | 101.60 | As required | As required |
| 6" | 152.40 | As required | As required |
Nickel 200 Tube Weight Chart
The theoretical weight of Nickel 200 Tubes depends on the outside diameter, wall thickness and length. The following values are approximate reference values based on the typical density of Nickel 200.
| Outside Diameter (mm) | Wall Thickness (mm) | Inside Diameter (mm) | Approx. Weight (kg/m) |
|---|---|---|---|
| 12.70 | 1.00 | 10.70 | 0.36 |
| 19.05 | 1.50 | 16.05 | 0.84 |
| 25.40 | 2.00 | 21.40 | 1.55 |
| 31.75 | 2.50 | 26.75 | 2.44 |
| 38.10 | 3.00 | 32.10 | 3.44 |
| 50.80 | 3.00 | 44.80 | 4.76 |
| 63.50 | 3.00 | 57.50 | 6.08 |
| 76.20 | 4.00 | 68.20 | 9.71 |
| 101.60 | 5.00 | 91.60 | 15.80 |
Note: The values shown are approximate theoretical weights. Actual tube weight may vary according to dimensions, tolerances, density and manufacturing conditions.
Nickel 200 Tube Standards
Nickel 200 Tubes can be supplied according to applicable ASTM, ASME and other industry specifications depending on product form, dimensions and application requirements.
| Standard / Designation | Details |
|---|---|
| UNS | N02200 |
| ASTM | ASTM B161 |
| ASME | ASME SB161 |
| Grade | Nickel 200 |
| Material Type | Commercially Pure Nickel |
Nickel 200 Tube Features
Nickel 200 Tubes offer a combination of corrosion resistance, ductility, thermal conductivity and electrical conductivity. The alloy is particularly suitable for reducing environments and caustic alkali applications.
- High nickel content
- Excellent resistance to caustic alkalis
- Good resistance to reducing environments
- Good ductility and toughness
- Good thermal conductivity
- Good electrical conductivity
- Excellent corrosion resistance in suitable environments
- Good resistance to distilled and natural waters
- Good resistance to dry fluorine
- Suitable for chemical and industrial applications
Nickel 200 Tube Chemical Composition
Nickel 200 is a commercially pure nickel alloy with a high nickel content and controlled amounts of carbon, manganese, iron, silicon, sulfur and copper. Its composition provides good corrosion resistance and physical properties.
| Element | Composition (%) |
|---|---|
| Nickel | 99.0 min. |
| Copper | 0.25 max. |
| Manganese | 0.35 max. |
| Iron | 0.40 max. |
| Silicon | 0.35 max. |
| Sulfur | 0.01 max. |
| Carbon | 0.15 max. |
Nickel 200 Tube Mechanical Properties
Nickel 200 provides good mechanical strength combined with excellent ductility and toughness. The actual mechanical properties depend on product condition, dimensions, heat treatment and applicable specification.
| Property | Typical Value |
|---|---|
| Tensile Strength | Approx. 462 MPa |
| Yield Strength | Approx. 148 MPa |
| Elongation | Approx. 40% |
| Density | Approx. 8.89 g/cm³ |
| Melting Range | Approx. 1435 - 1446°C |
Note: Mechanical properties vary according to product form, dimensions, temper and applicable specification. Certified material test reports should be used for final verification.
Nickel 200 Tube Equivalent Grades
| Designation | Nickel 200 |
|---|---|
| UNS | N02200 |
| EN | 2.4066 |
| Trade Name | Nickel 200 |
| Material Type | Commercially Pure Nickel |
Nickel 200 Tube vs Nickel 201 Tube
Nickel 200 and Nickel 201 are commercially pure nickel grades with similar corrosion resistance and physical properties. Nickel 201 has a lower carbon content, making it more suitable for certain high-temperature applications where carbon pickup or graphitization can be a concern.
| Property | Nickel 200 | Nickel 201 |
|---|---|---|
| UNS | N02200 | N02201 |
| Nickel Content | High | High |
| Carbon Content | Higher than Nickel 201 | Lower |
| Corrosion Resistance | Excellent in suitable environments | Excellent in suitable environments |
| High-Temperature Use | More limited | Better suited to certain higher-temperature applications |
Nickel 200 Tube Applications
Nickel 200 Tubes are used in applications requiring commercially pure nickel with excellent corrosion resistance, good ductility and reliable performance in reducing and caustic environments.
Chemical Processing
Used in chemical processing equipment and systems handling caustic alkalis and selected reducing chemicals.
Caustic Handling Equipment
Used in equipment exposed to sodium hydroxide and other caustic alkaline solutions.
Heat Exchangers
Used in selected heat-transfer and tubular equipment where nickel's corrosion resistance is required.
Electrical Equipment
Used in selected electrical and electronic applications because of its good electrical conductivity.
Food Processing
Used in selected food-processing equipment where corrosion resistance and material compatibility are important.
Industrial Equipment
Used in specialized industrial systems requiring commercially pure nickel and good corrosion resistance.
Industries Using Nickel 200 Tubes
Kamal Steels supplies Nickel 200 Tubes to industries requiring commercially pure nickel tubing for corrosive, chemical and specialized operating environments.
Chemical Industry
Used in chemical processing systems and equipment exposed to caustic and reducing environments.
Petrochemical Industry
Used in selected process equipment and tubular systems requiring corrosion-resistant nickel materials.
Electrical Industry
Used in specialized electrical and electronic components requiring good conductivity and corrosion resistance.
Food Processing Industry
Used in selected processing equipment where corrosion resistance and material compatibility are required.
Power Generation Industry
Used in selected industrial and power-generation equipment requiring corrosion-resistant nickel tubing.
Engineering Industry
Used for specialized components and equipment requiring commercially pure nickel and good mechanical performance.
Frequently Asked Questions
Nickel 200 Tubes are commercially pure nickel alloy tubes manufactured from Nickel 200 (UNS N02200 / WNR 2.4066). They are widely used in applications requiring exceptional corrosion resistance, high purity, and excellent thermal and electrical conductivity.
Our Nickel 200 Tubes are manufactured according to ASTM B161, ASTM B163, ASTM B725, ASTM B730, ASME SB161, and ASME SB163 standards.
Nickel 200 Tubes provide excellent corrosion resistance, outstanding thermal and electrical conductivity, superior ductility, excellent weldability, and long service life in chemically aggressive environments.
They are widely used in chemical processing plants, food processing equipment, heat exchangers, electronics, marine engineering, aerospace, pharmaceutical manufacturing, and power generation industries.
Yes. Nickel 200 offers outstanding resistance to caustic alkalis, neutral and reducing chemicals, making it ideal for chemical processing applications.
Each tube undergoes PMI Testing, Chemical Analysis, Mechanical Testing, Hydrostatic Testing, Ultrasonic Testing (UT), Eddy Current Testing (ECT), Flattening, Flaring, Dimensional Inspection, and Visual Inspection.
Yes. Due to their high purity, corrosion resistance, and excellent hygienic properties, Nickel 200 Tubes are commonly used in food processing and pharmaceutical industries.
Yes. Every shipment includes EN 10204 3.1/3.2 Mill Test Certificates, inspection reports, complete material traceability, and third-party inspection certificates upon request.
Yes. Kamal Steels exports Nickel 200 Tubes worldwide with export-standard packaging, complete documentation, and timely international delivery.
Kamal Steels offers ASTM-compliant Nickel 200 Tubes with ready stock, certified quality, competitive pricing, stringent quality control, export-standard packaging, complete documentation, and dependable worldwide delivery for critical industrial applications.
