Duplex Steel UNS S32205 Seamless Tubes Manufacturer in India
What Are Duplex Steel UNS S32205 Seamless Tubes?
Duplex Steel UNS S32205 Seamless Tubes are tubular products manufactured from duplex stainless steel with a balanced austenitic and ferritic microstructure. UNS S32205, commonly known as Duplex 2205, provides a combination of high mechanical strength, good toughness, excellent corrosion resistance and resistance to chloride-induced stress corrosion cracking.
Duplex Steel UNS S32205 Seamless Tubes are valued for their high strength-to-weight ratio, excellent resistance to pitting and crevice corrosion, good chloride resistance and reliable performance in demanding environments. Their seamless construction provides a continuous tubular structure without a longitudinal weld, making them suitable for pressure, process and heat-transfer applications.
These seamless tubes are used in oil and gas equipment, petrochemical plants, chemical processing systems, marine applications, heat exchangers, desalination plants, power generation and wastewater treatment equipment. The tube grade, outside diameter, wall thickness, schedule, length and finish are selected according to operating conditions and applicable material specifications.
Kamal Steels is a reliable Duplex Steel UNS S32205 Seamless Tubes Manufacturer and Stockist in India, supplying seamless tubes in different sizes, wall thicknesses, schedules, lengths and finishes according to customer and project requirements. We also cater to international requirements with suitable export packaging, MTC and documentation.
Table of Contents
- Duplex Steel UNS S32205 Seamless Tube Specifications
- Duplex Steel UNS S32205 Seamless Tube Size Chart
- Duplex Steel UNS S32205 Seamless Tube Weight Chart
- Duplex Steel UNS S32205 Seamless Tube Standards
- Duplex Steel UNS S32205 Seamless Tube Features
- Duplex Steel UNS S32205 Chemical Composition
- Duplex Steel UNS S32205 Mechanical Properties
- Duplex Steel UNS S32205 Equivalent Grades
- UNS S32205 Seamless Tubes vs UNS S31803 Seamless Tubes
- Duplex Steel UNS S32205 Seamless Tube Applications
- Industries Using UNS S32205 Seamless Tubes
- Frequently Asked Questions
Duplex Steel UNS S32205 Seamless Tube Specifications
Duplex Steel UNS S32205 Seamless Tubes are supplied in different dimensions and product conditions according to applicable ASTM, ASME and international standards. Custom sizes and lengths can be supplied according to project requirements.
| Specification | UNS S32205 Seamless Tubes |
|---|---|
| Material | Duplex Stainless Steel |
| Grade | UNS S32205 |
| Common Name | Duplex 2205 |
| Tube Type | Seamless |
| ASTM Standard | ASTM A789 |
| ASME Standard | ASME SA789 |
| Outside Diameter | As per requirement |
| Wall Thickness | As per requirement |
| Schedule | As required |
| Length | Random, Fixed or Customized |
| Finish | Pickled, Annealed, Polished or As required |
Duplex Steel UNS S32205 Seamless Tube Size Chart
Duplex Steel UNS S32205 Seamless Tubes are available in various outside diameters and wall thicknesses for process, pressure, heat-transfer and industrial applications. Custom dimensions can also be supplied according to customer drawings and requirements.
| Tube Size | Outside Diameter (mm) | Wall Thickness | Length |
|---|---|---|---|
| 1/2" | 12.70 | As required | As required |
| 3/4" | 19.05 | As required | As required |
| 1" | 25.40 | As required | As required |
| 1-1/2" | 38.10 | As required | As required |
| 2" | 50.80 | As required | As required |
| 3" | 76.20 | As required | As required |
| 4" | 101.60 | As required | As required |
| 6" | 152.40 | As required | As required |
| 8" | 203.20 | As required | As required |
Duplex Steel UNS S32205 Seamless Tube Weight Chart
The weight of Duplex Steel UNS S32205 Seamless Tubes depends on outside diameter, wall thickness and length. The following values are approximate theoretical references, and actual weight may vary according to dimensions and manufacturing tolerances.
| Outside Diameter (mm) | Wall Thickness (mm) | Inside Diameter (mm) | Approx. Weight (kg/m) |
|---|---|---|---|
| 12.70 | 1.00 | 10.70 | 0.35 |
| 19.05 | 1.50 | 16.05 | 0.83 |
| 25.40 | 2.00 | 21.40 | 1.51 |
| 31.75 | 2.50 | 26.75 | 2.38 |
| 38.10 | 3.00 | 32.10 | 3.35 |
| 50.80 | 3.00 | 44.80 | 4.65 |
| 63.50 | 3.00 | 57.50 | 5.94 |
| 76.20 | 4.00 | 68.20 | 9.49 |
| 101.60 | 5.00 | 91.60 | 15.43 |
Note: Weight values are approximate theoretical references. Final weight should be verified against actual dimensions and material test documentation.
Duplex Steel UNS S32205 Seamless Tube Standards
Duplex Steel UNS S32205 Seamless Tubes can be supplied according to applicable ASTM, ASME and other international standards depending on product dimensions, application and customer requirements.
| Standard / Designation | Details |
|---|---|
| UNS | S32205 |
| Common Name | Duplex 2205 |
| ASTM | ASTM A789 |
| ASME | ASME SA789 |
| Product Form | Seamless Tube |
Duplex Steel UNS S32205 Seamless Tube Features
UNS S32205 is widely selected for demanding applications requiring high strength and excellent corrosion resistance. Its duplex microstructure provides a useful combination of mechanical and corrosion-resistant properties.
- High mechanical strength
- Excellent resistance to pitting corrosion
- Good resistance to crevice corrosion
- Good resistance to chloride-induced stress corrosion cracking
- High strength-to-weight ratio
- Good toughness and durability
- Good resistance to general corrosion
- Reliable performance in chloride-containing environments
- Suitable for demanding process applications
- Seamless construction without a longitudinal weld
Duplex Steel UNS S32205 Chemical Composition
The chemical composition of UNS S32205 includes controlled levels of chromium, nickel, molybdenum and nitrogen. This alloying balance contributes to its high strength and resistance to localized corrosion.
| Element | Composition (%) |
|---|---|
| Chromium | 22.0 - 23.0 |
| Nickel | 4.5 - 6.5 |
| Molybdenum | 3.0 - 3.5 |
| Nitrogen | 0.14 - 0.20 |
| Carbon | 0.030 max. |
| Manganese | 2.00 max. |
| Silicon | 1.00 max. |
| Phosphorus | 0.030 max. |
| Sulfur | 0.020 max. |
| Iron | Balance |
Duplex Steel UNS S32205 Mechanical Properties
UNS S32205 provides high tensile and yield strength along with good elongation and toughness. Actual mechanical properties depend on product form, dimensions, heat treatment and applicable material specification.
| Property | Minimum Requirement |
|---|---|
| Tensile Strength | 620 MPa min. |
| Yield Strength | 450 MPa min. |
| Elongation | 25% min. |
| Density | Approx. 7.8 g/cm³ |
Note: Mechanical requirements can vary according to product form, dimensions and applicable specification. Certified material test reports should be used for final verification.
Duplex Steel UNS S32205 Equivalent Grades
| Designation | Equivalent / Related Grade |
|---|---|
| UNS | S32205 |
| Common Name | Duplex 2205 |
| EN Material Number | 1.4462 |
| EN Grade | X2CrNiMoN22-5-3 |
UNS S32205 Seamless Tubes vs UNS S31803 Seamless Tubes
UNS S32205 and UNS S31803 are closely related duplex stainless steel grades associated with Duplex 2205. UNS S32205 is the commonly specified 2205 grade with a more tightly controlled composition. Both grades provide high strength and excellent corrosion resistance, but the applicable specification and material certificate should always be checked for the required product.
| Property | UNS S32205 | UNS S31803 |
|---|---|---|
| Material Type | Duplex Stainless Steel | Duplex Stainless Steel |
| Common Name | Duplex 2205 | Duplex 2205 |
| Corrosion Resistance | Excellent | Excellent |
| Strength | High | High |
| Typical Service | Demanding duplex applications | Process and industrial applications |
Duplex Steel UNS S32205 Seamless Tube Applications
Duplex Steel UNS S32205 Seamless Tubes are used in applications requiring high mechanical strength, excellent corrosion resistance and reliable performance in demanding process environments.
Oil & Gas
Used in process equipment, piping systems and tubular components exposed to corrosive oil and gas environments.
Petrochemical Plants
Used in process systems and equipment requiring high strength and corrosion-resistant tubular products.
Chemical Processing
Used in chemical processing equipment exposed to corrosive chemicals and chloride-containing environments.
Marine Applications
Used in marine equipment and seawater systems requiring resistance to chloride-related corrosion.
Heat Exchangers
Used in heat-transfer systems requiring durable and corrosion-resistant tubing.
Desalination
Used in desalination and water-treatment equipment exposed to chloride-rich operating conditions.
Industries Using Duplex Steel UNS S32205 Seamless Tubes
Kamal Steels supplies Duplex Steel UNS S32205 Seamless Tubes to industries requiring high-strength and corrosion-resistant tubular products for demanding operating conditions.
Oil & Gas Industry
Used in exploration, production and processing equipment where strength and corrosion resistance are required.
Petrochemical Industry
Used in process equipment and piping systems exposed to demanding chemical and corrosive conditions.
Chemical Industry
Used in chemical processing systems requiring reliable corrosion-resistant materials.
Marine Industry
Used in marine and seawater applications where resistance to chloride environments is important.
Power Generation Industry
Used in selected power and cooling systems requiring durable corrosion-resistant tubing.
Water Treatment Industry
Used in desalination, water treatment and wastewater processing systems.
Frequently Asked Questions
Duplex Steel UNS S32205 Seamless Tubes are high-strength stainless steel tubes manufactured without welded joints. They provide excellent corrosion resistance, superior mechanical strength, and reliable performance in high-pressure and highly corrosive industrial applications.
Our Duplex Steel UNS S32205 Seamless Tubes are manufactured according to ASTM A789, ASTM A790, ASME SA789, and ASME SA790 standards.
These seamless tubes offer excellent mechanical strength, outstanding resistance to chloride stress corrosion cracking, pitting, crevice corrosion, superior pressure resistance, and long service life.
They are widely used in offshore oil & gas platforms, marine engineering, desalination plants, chemical processing facilities, petrochemical industries, heat exchangers, pressure vessels, and power generation systems.
UNS S32205 has tighter chemical composition limits with optimized chromium, molybdenum, and nitrogen content, providing improved corrosion resistance and more consistent mechanical properties compared to UNS S31803.
Each tube undergoes PMI Testing, Chemical Analysis, Mechanical Testing, Hydrostatic Testing, Ultrasonic Testing (UT), Eddy Current Testing (ECT), Dimensional Inspection, Surface Inspection, and Visual Inspection.
Yes. Duplex Steel UNS S32205 provides excellent resistance to seawater corrosion, chloride-induced pitting, crevice corrosion, and stress corrosion cracking, making it ideal for offshore and marine applications.
Yes. Every shipment includes EN 10204 3.1/3.2 Mill Test Certificates, inspection reports, complete material traceability, and third-party inspection certificates upon request.
Yes. Kamal Steels exports Duplex Steel UNS S32205 Seamless Tubes worldwide with export-standard packaging, complete documentation, and timely international delivery.
Kamal Steels offers ASTM-compliant Duplex Steel UNS S32205 Seamless Tubes with ready stock, certified quality, competitive pricing, stringent quality control, export-standard packaging, complete documentation, and dependable worldwide delivery for critical industrial applications.
